15
4. Technical Specifications
Parameters Unit SHBW10000
Dimensions mm 51 x 51 x 68
Weight g 68
Operating Temperature °C 0 – 40
Max. Humidity % 90
IP Class 20
Radio frequency MHz 868,42 (Z-Wave PLUS, Europe)
Modulation FSK (BFSK/GFSK)
Transmission power db < 4,5
Power supply 3 V DC
Battery type CR123
Power consumption standby mA 0,015
Power consumption trigger mA 38
Battery-life
2 years (12 Multisensor-Trigger+50 PIR
Trigger+24 times wakeup per day)
Range (open field) m 100
Range (building) m 20, related to material of walls
Temperature Measuring range °C 0-40
Humidity Measuring range % 0-90
Light sensor Measuring range Lux 0-65528
measurement accuracy ± 1
Tamper protection Nein
Firmware upgradeable Yes
Support Z-Wave Beaming No
SmartStart supported Yes
Z-Wave Network Security Yes
Z-Wave AES-128 Security Yes
Z-Wave Plus Yes
Security S2 Classes Yes
Z-Wave Chip Generation 500
Z-Wave Sensor-Typ Open/Closed (Binary)
Z-Wave library type Enhanced 232 Slave
Device Type / Role type
Notification sensor /
Reporting sleeping slave
