ADDING MORE FANS
The CONTROLLER 69 is built with four ports that enable you to power and control multiple fans
at the same time. Compatible with inline fans with EC motors only. See image below for a sample
configuration.
Multi-Fan Connection
INLINE FAN 4" INLINE FAN 6"
MOLEX ADAPTER
Use the included UIS to 4-pin Molex adapter to connect your fan to the Universal Controller (not
included). Plug your fan's UIS connector into the adapter. Then plug the adapter into your controller.
