INSTALLATION
LIGHT BAR CHAIN ASSEMBLY
1
2
3
MF
STEP 1
Connect the single-corded LED light bar's
female port to the dual-corded LED light bar's
male connector.
STEP 2
Connect the EC power adapter's male
connector to the other end of the dual-corded
LED light bar.
EXTENDING THE CHAIN
You may connect the included bar extension
cord in between any link in this light bar chain
to lengthen it. Secure all connections using the
twist-on pieces.
STEP 3
Connect the power adapter to the
schedule controller.
