ACCEL DFI Engine Analyzer Series User Manual

15
No
te: All input and output drivers are active low. For
example, in order to trigger data logging, the input
wire (AuxIn1, Pin 7, Color: Green with Yellow trace)
will be activated by switching the input wire to a
ground source. Similarly, any output wire should be
connected to the ground trigger of a relay for proper
operation.

ACCEL DFI Engine Analyzer Series Specifications

General

Brand	ACCEL DFI
Model	Engine Analyzer Series
Category	Measuring Instruments
Language	English
