2
Engine Analyzer Series
Wideband Oxygen Sensor
In
troduction
Co
ngratulations on the purchase of your new Accel DFI “Engine Analyzer Series”
wideband oxygen sensor kit! This system uses the latest available technology to
offer unparalleled accuracy, repeatability, and reliability. The durable water resistant
enclosure and harness assembly make it an ideal choice for installation under the
hood or under the chassis.
All Engine Analyzer Series kits include integrated Data Logging functions, and are
available with a host of options and configurations to suit virtually any application.
The following is a list of available part numbers in the Engine Analyzer Series along
with the associated parts and configurations for each number:
77062 – includes electronic control module, wiring harness, and sensor.
77062N - includes electronic control module and wiring harness. This kit does
not contain a sensor.
Optional sensors are available under part number 77065 (Lab grade) O2
sensor or a 77061 (Standard grade) sensor. The unit is configurable for both
types.
77062S - includes electronic control module, wiring harness, and sensor
described above along with a single 2 1/16” digital air/fuel ratio gauge.
77063 - includes electronic control module, wiring harness, and (2) sensors
can be connected simultaneously for monitoring air/fuel ratio information in
dual exhaust applications.
77063S – includes one 2 1/16” digital air/fuel ratio gauge. This gauge
features an easy-to-read digital display and multi-color LED sweep gauge for
readability at a glance.
This manual contains instructions and wiring schematics for each part number listed
above.
