Accu-Chek Aviva Nano User Manual

6. Put the meter on a flat surface. Point the two IR windows toward each other. They
should be 3 to 10 cm apart.
7. Do not move the infrared cable
(computer), PDA, or meter during the
transfer.
8. Follow the prompts on the software.
9. The software program may shut off
the meter automatically when the data
transfer is complete.
Notes:
If the data did not transfer successfully, try again. If you still have problems, contact •
Accu-Chek Customer Care at 1-800-363-7949.
To make the most of the download feature, you must set the time and date in the •
meter correctly.
49
43604_NanoAv_12hr_Ins_EN.indd 49 11/24/08 11:08:45 AM

Accu-Chek Aviva Nano Specifications

General

Blood Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Measuring Range	10-600 mg/dL
Battery	1 x 3V CR2032 lithium battery
Storage Conditions	-25°C to 70°C
Memory	500 test results
Weight	Approx. 40 g (with battery)
