AcuDC 240 Series
DC Energy & Power meters
Current Inputs
1. Preparing for Safe Removal
If the meter was wired directly in series to the current carrying lines without the use of a
shunt/Hall effect sensor then the operator must de-energize the circuit before removing
the circuit wires from the AcuDC meter.
2. Disconnecting the current inputs
Using a #2 flat head screw driver, screw driver, turn the screws on pins 5 and pin 6
counter-clock wise. Stop turning when the wire can be easily removed from its housing.
Cleaning the Meter
ACCUENERGY recommends using a dry cloth to wipe the meter.
