Ace AT Series User Manual

Section 8 – Maintenance
Page | 12
ELECTRICAL RATINGS
Model Number
Part No.
Input Voltage
(VAC -50/60Hz)
Max. AC
Load Current
(RMS Amps)
Armature
Voltage (VDC)
Max. DC
Load Current
(DC Amps)
Max.
Horsepower
HP, (kW)
KBWM – 120
9380
115
5.0
0 - 90
3.5
1/3,(0.25)
PLUG-IN HORSEPOWER RESISTOR® CHART
90 VDC
Max Horsepower
Range
Approx.
Motor Current
(DC Amps)
Plug-in Horsepower
Resistor® Value
(OHMS)
Individual
Plug-in Horsepower®
Resistor Part No.
1/8
1.3
0.1
9838
1/4
2.5
0.05
9839
AMATURE FUSE SELECTION CHART
90 VDC
Max Horsepower
Range
Approx.
Motor Current
(DC Amps)
Fuse
Rating
(AC Amps)
1/8
1.3
2
1/4
2.5
4
