10 Chapter 1
Left View
Right View
# Icon Item Description
1 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
2 Optical drive Internal optical drive; accepts CDs or
DVDs.
3 Optical disk access
indicator
Lights up when the optical drive is active.
4 Optical drive eject
button
Ejects the optical disk from the drive.
5 Emergency eject hole Ejects the optical drive tray when the
computer is turned off.
6 PC Card slot eject
button
Ejects the PC Card from the slot.
7 PC Card slot Accepts on Type II PC Card.
# Icon Item Description
1 Three USB 2.0 ports Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
2 Ventilation slots Enable the computer to stay cool, even
after prolong use.
3 Modem (RJ-11) port Connects to a phone line.
