Acer 2420 - Indicators

12 Chapter 1
Indicators
The computer has four easy-to-read status indicators on the upper-right above the keyboard, and four on the
front panel.
Aspire 3620:
TravelMate 2420:
The power, battery and wireless communication status indicators are visible even when the LCD display is
closed.
3 Hard disk bay Houses the computer’s hard disk (secured
with screws)
4 Memory compartment Houses the computer’s main memory.
5 Battery release latch Release the battery for removal.
6 Battery bay Houses the computer’s battery pack.
