18
English
Right view
Rear view
# Icon Item Description
1 PC Card slot eject
button
Ejects the PC Card from the slot.
2 PC Card slot Accepts one Type II PC Card.
3 Two USB 2.0 ports Connect to USB 2.0 devices
(e.g., USB mouse, USB camera).
4 Ventilation slots Enable the computer to stay cool, even
after prolonged use.
5 External display
(VGA) port
Connects to a display device
(e.g., external monitor, LCD projector).
# Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 USB 2.0 port Connect to USB 2.0 devices
(e.g., USB mouse, USB camera).
3 Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/1000-
based network. (for selected models)
4 Modem (RJ-11) port Connects to a phone line.
5 Battery Powers the computer.
6 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
