Acer AL1717 - Monitor Board Layout

- 22 -
Monitor board layout
LABEL Component LABEL Component
U1 24LVC2B CN1 D-SVB 15 PIN
U3 TSU16AJ CN6 E&T 4501-19
U6 24LC16B(24LVO2B) CN3 E&T 4501-09
U5 MX810 J502 E&T 4501-05
U7 APM4461 J501 E&T 4501-03
U4 PMX10E8D50I CN5 P-TWO AFN300 30P
U8 APL1085-3.3 CE
U9 APL1117-2.5 VC
U501 ATPA6019
CN5
CM6
J502
J501
CN3
