Acer AL2016

Acer Service Manual
Attachment 1- Bill of Material
PCBA Power Board
ITEM P/N DESCRIPTION qty LOCATION
1 430300800410R HRN ASS'Y 8P 60mm UL1007#24, 1 CN801
2 412140002380R IC LTV817M-PR VDE (LITE-ON)P=10mm 1 IC801
2.1 412140001390R IC EL817M-B ROHS (EVERLIGHT 1
3 411050005020R DIO BRDG BL4-06-BF52-LF 1 D801
600V/4A FRONTIER ROHS
4 416194743011R CAP MEX 0.47uF 275V K X2,F15 1 C803
5 416202224610R CAP MEY 2200pF 400V M Y,F10mm 1 C813
6 416202223610R CAP MEY 2200pF 250V M Y2 Y5V P=7.5mm 2 C801,C802
7 420421020211R CAP SD 1000uF 25V M,105 F13x20℃ 2 C815,C816
8 420431514280R CAP SEK 150uF/420V M,105 CF18x40℃ 1 C804
9 425000010530R COIL CHK 5uH 7.8X10 CHK-053 0 2 L802,L803
181085R0L-LFR ROHS
10 425000010680R COIL CHK 110uH T50-26B CHK-068 2 L804,L805
ROHS,BC1306IR-111K-J
11 425000010670R COIL CHK 20mH UU16 CHK-067,ROHS 1 L801
UF2324S4-203Y1R0-X02
12 426000090560R XFMR SW 360uH HE-4 SPW-056,DIP 1 T801
13 432009400701R NTC 5Ω 4A 10ψ P=5mm, F ROHS 1 RT801
14 430613420290R FUSE SLOW 2,250,Axial Lead,3.6x10mm 1 F801
15 440149000190R SKT AC 10A/250V U/C/V G/Y=65mm 1 P801
TU-301-SP-SR7-AC3+019
16 415350104551R RES MOF 2W 100KΩ J,MINI,HK17.5 1 R813
17 511110000101R HOT-MELT ADHESIVES (#526) 0.003
18 418247233020R CAP CD X7R 4700pF 1KV K,W/O FORMING, 1 C806
19 415350308551R RES MOF 2W 0.3Ω J,MINI,HK17.5 1 R815
20 430300600080R HRN ASS'Y 6P 30mm UL1007#24, 1 CN802
21 416204724610R CAP MEY 4700pF 400V M Y,F10mm 1 C835
22 735100006500R ASSY,H/S,UFF80-015, LE2016 1
23 411020065020R DIO UFF80-015CT-LF 150V/8A, 1 D807
ITO-220AC(FRONTIER)ROHS
24 507200003800R HEATSINK,56x20xt10mmLE1904/05 1
25 509112306100R SCREW,P,CROSS,T.T-3*6,Zn 1
26 735100006510R ASSY,H/S,AP2761I-A,LE2016 1
27 410500059290R XSTR AP2761I-A N-CH TO-220CFM 1 Q804
ADVANCED POWER ROHS
27.1 410050061130R XSTR SPA07N65C3 N-CH PG-TO220- 1
3-31(INFINEON)ROHS
28 507200003700R HEATSINK,46x20xt10mmLE1704/05 1 H801
29 509112306100R SCREW,P,CROSS,T.T-3*6,Zn 1
30 790450540900R PCBA,POWER BOARD,SMD, LE2016 1
31 410500045210R XSTR PMBT3904 NPN 200MA,40V 2 Q803,Q805
