SOT23(PHILIPS) ROHS
31.1 410500045130R XSTR MMBT3904 NPN SOT-23(INFINEON) 2
31.2 410500045140R XSTR MMBT3904LT1G NPN 200MA 2
40V SOT23 ROHS (ON)
32 411150356950R ZENER 5.6V MTZS05-5.6-G,ROHS 1 ZD804
SOD-123 (MMC)
32.1 411100656951R ZENER 5.6V ZMM5232B-LF DO213AA 1
(FRONTIER)ROHS
32.2 411101156920R ZENER BZV55-B5V6 SOD80C,ROHS(PHILIPS) 1
33 411101139950R ZENER BZV55-C3V9 SOD80C(PHILIPS) 1 ZD805
33.1 411150339950R ZENER 3.9V MTZS05-3.9-G,SOD-123(MMC) 1
33.2 411100639950R ZENER 3.9V ZMM55-C3V9-LF DO-213AA(FEC) 1
34 411150312050R ZENER 12V MTZS05-12-G,SOD-123(MMC) 1 ZD806
34.1 411154012050R ZENER 12V ZMM55-C12-LF SMD(FEC 1
DO-213AA ROHS
34.2 411101112050R ZENER BZV55-C12 SOD80C(PHILIPS 1
35 411150315050R ZENER 15V MTZS05-15-G,SOD-123(MMC) 1 ZD802
35.1 411101115020R ZENER BZV55-B15 SOD80C(PHILIPS 1
35.2 411100615051R ZENER 15V ZMM5245B-LF DO-213AA(FEC) 1
36 411101120050R ZENER BZV55-C20 SOD80C(PHILIPS 1 ZD803
36.1 411150320050R ZENER 20V MTZS05-20-G SOD-123(MITSUBISHI) 1
36.2 411100620050R ZENER 20V ZMM55-C20-LF DO-213AA(FRONTIER) 1
37 411150339050R ZENER 39V MTZS05-39-G,SOD-123(MMC) 1 ZD801
37.1 411100539050R ZENER MMSZ39T1G SOD-123(ON) 1
37.2 411101139050R ZENER BZV55-C39 SOD80C(PHILIPS 1
38 412000412840R IC NCP1203D60R2G SO-8(ON)ROHS 1 IC802
39 414908010350R RES SMD (0805) 10KΩ J,RT ROHS 2 R804,R811
40 414908010250R RES SMD (0805) 1KΩ J,RT ROHS 7 R812,R820,R821,R827,R830,R839,R828
41 414908068450R RES SMD (0805) 680KΩ J,RT 6 R805,R806,R807,R808,R836,R835
42 414916200210R RES SMD (0603) 20KΩ F,RT 1 R823
43 414908330110R RES SMD (0805) 3.3KΩ F,RT 1 R822
44 414916120110R RES SMD (0603) 1.2KΩ F,RT 2 R825,R833
45 414904010050R RES SMD (1206) 10Ω J,RT ROHS 1 R816
46 414916020210R RES SMD (0603) 2KΩ F,RT ROHS 1 R834
47 414916750110R RES SMD (0603) 7.5KΩ F,RT 2 R826,R838
48 414904010550R RES SMD (1206) 1MΩ J,RT ROHS 2 R801,R802
49 414908510010R RES SMD (0805) 510Ω F,RT,ROHS 1 R837
50 419311040070R C SMD(0805) X7R 0.1uF/50V K 2 C810,C834
51 419311030060R C SMD(0603) X7R 0.01uF/50V K 2 C822,C831
52 419301010560R C SMD(0603) NPO 100PF/50V J 1 C826
53 419311030070R C SMD(0805) X7R 0.01uF/50V K 1 C812
54 419311040060R C SMD(0603) X7R 0.1uF/50V K 4 C819,C824,C828,C830
55 419302210360R C SMD(0603) NPO 220PF/50V G 1 C811
56 419341064650R C SMD(1206) Y5V 10uF/16V Z 1 C805
57 412000429840R IC MC33063ADR2G SOIC8(ON)ROHS 2 IC804,IC805
