Acer AL2016

Acer Service Manual
58 411090020410R SCHTKY SKS20-04AT-G 40V/2ATHIN SMA (MMC) 4 D808,D810,D811,D812
59 410500060290R XSTR AP9435GH P-CH TO-252 ROHS 2 Q802,Q806
ADVANCED POWER
60 414908022250R RES SMD (0805) 2.2KΩ J,RT 1 R829
61 419303300560R C SMD(0603) NPO 33PF/50V J 1 C829
62 790450510900R PCBA,POWER BOARD,AI, LE2016 1
63 790450550900R PCBA,POWER BOARD,AI/A, LE2016 1
64 415130680540R RES CF 1/2W 68Ω J,AT ROHS 1 R814
65 415340228540R RES MOF 1W 0.22Ω J,AT MINI 1 R831
66 415130102540R RES CF 1/2W 1KΩ J,AT ROHS 1 R819
67 415130183540R RES CF 1/2W 18KΩ J,AT,ROHS 1 R803
68 415320100540R RES MOF 1/4W 10Ω J,AT MINI 1 R809
69 415320471540R RES MOF 1/4W 470Ω J,AT,ROHS 1 R810
70 415340151540R RES MOF 1W 150Ω J,AT MINI 4 R824,R832,R818,R840
71 411020052020R DIO A02-LF 200V/1A R1 (FEC) 1 D805
71.1 411030003040R DIO FR103 200V/1A DO-41(MOSPEC 1
72 411022003210R DIO 1N4148 75V/0.2A AT (PHIL) 4 D814,D813,D803,D806
72.1 411022003020R DIO 1N4148-LF 75V/0.15A AT(FEC) 4
73 411020055330R DIO MUR1100ERL AXIAL LEAD(ON) 1 D804
73.1 411032006020R DIO FR10-10-LF 1000V/1A AT(FRONTER) 1
74 411020063240R DIO 1N4007 1000V/1A DO-41(FAIRCHILD) 1 D802
74.1 411020063020R DIO 1N4007-LF 1000V/1A DO-41(FRONTIER) 1
75 430405007590R JMPR 7.5mm D=0.6mm,AT ROHS 6 J801,J802,J803,J804,J809,J811
76 430405010090R JMPR 10mm D=0.6mm,AT ROHS 8 J806,J807,J808,J810,J812,J813,J814,J815
77 506140005700R LABEL,BARCODE,BLANK,33x7mm, 1
ROHS,FOR PCB
78 490450500100R PCB,POWER, LE2016 ROHS 1 PCB
79 430405012590R JMPR 12.5mm D=0.6mm,AT ROHS 1 J805
80 432002200160R BEAD CORE BF30TA-3.5x9x0.8AT 2 B801,B802
81 415340158540R RES MOF 1W 0.15Ω J,AT MINI 1 R817
82 790450560900R PCBA,POWER BOARD,AI/R, LE2016 1
83 418147038530R CAP CD NPO 47pF 1KV J,VT ROHS 1 C823
84 418210227030R CAP CD X7R 1000pF 500V K VT 1 C814
85 418310413630R CAP CD Y5V 0.1uF 50V Z,VT 1 C809
86 420434700230R CAP EC 47uF 25V M,105 VT5x11℃ 3 C807,C820,C833
87 416231041530R CAP MEB 0.1uF 100V J,(RSB),VT 1 C821
RSBEC3100DQJ ROHS
88 418210233030R CAP CD X7R 1000pF/1KV K,VT 1 C808
2X7R102K102K56 ROHS
89 420424710260R CAP SD 470uF/25V M 105 ST10x16℃ 3 C817,C818,C827
90 420424710130R CAP SD 470uF/10V M,105 8x12 ℃ 2 C825,C832
91 412022002840R IC TLV431ALP TO-92 1%,VT (ON) 1 IC803
91.1 412022002240R IC KA431AZ 1%,VT (FAIRCHILD) 1
91.2 412022002300R IC AP431VL TO-92 1% VT (ATC) 1
92 410072013370R XSTR 2SC1815-GR (T2SPF.T) VT(TOSHIBA) 1 Q801
