92.1 410072013210R XSTR 2PC1815GR*I VT (PHILIPS) 1
92.2 410072013150R XSTR UTC2SC1815L-GR NPN TO92,ROHS(UTC) 1
PCBA IF Board
ITEM P/N DESCRIPTION qty LOCATION
1 790451320900R PCBA,IF BOARD,OTHER,LE2016-9J0 1
2 430631080070R WFR 2.0mm 8P 180°4500-08 ROHS 1 CN101
3 440819015070R
CON,D-SUB,FEM.15P RA W/O SCREW
DV11201-H5K8-4F
1 CN102
4 430631080030R WFR 2.0mm 8P R/A HF5608E ROHS 1 CN103
5 430631300010R WAFER 2x15P 2.0mm 180°,ROHS 1 CN105
6 420431010461R CAP EC 100uF 16V M,105 ST5℃ x11(SK) 4 C102,C103,C111,C114
7 420431000260R CAP EC 10uF 25V M,105 ST5x11 ℃ 12
C116,C131,C145,C157,C160,C16
1,C162,C163,C174,C175,C188,C2
07
8 432008010340R XTAL 12MHz AT-49 DIP,16pF 30PPM 1 X101
9 432008010270R XTAL 14.31818MHz HC-49US DIP16pF 30PPM 1 X102
10 420421010460R CAP SD 100uF 16V M,105 ST,5x11℃ 1 C109
11 790451340900R PCBA,IF BOARD,SMD, LE2016-9J0 1
C101,C106,C107,C108,C110
C112,C113,C115,C124,C125
C126,C127,C128,C132,C137
C138,C139,C140,C141,C142
C143,C144,C146,C147,C148
C149,C150,C151,C152,C153
C154,C155,C156,C158,C159
C164,C165,C166,C167,C168
C169,C170,C171,C172,C173
C176,C177,C178,C181,C182
C183,C186,C190,C191,C192
C193,C194,C195,C196,C197
C198,C199,C200,C201,C202
C203,C206,C209,C210,C211
C212,C213,C214,C215,C216
12
419311040060R
C SMD(0603) X7R 0.1uF/50V K 76
C205
13 419341054670R C SMD(0805) Y5V 1uF/16V Z ROHS 4 C105,C189,C136,C208
14 419311030060R C SMD(0603) X7R 0.01uF/50V K 9
C117,C118,C119,C120,C121,
C122,C123,C187,C204
15 419304700560R C SMD(0603) NPO 47PF/50V J 2 C130,C129
16 419301500560R C SMD(0603) NPO 15PF/50V J 4 C134,C135,C179,C180
17 411020062020R DIO SM4001-LF 50V/1A MELF(FRONTIER) 1 D101
17.1 411020066450R DIO SR4004PT 400V/1A MELF(CHENMKO) 1
18 411020047020R DIO BAV70-LF 70V SOT23 (FEC) 1 D102
18.1 411020047210R DIO BAV70 85V SOT23 (PHILIPS) 1
