Acer AL2016

Acer Service Manual
19 411020026210R DIO BAV99 350mW 70V SOT-23(PHI 4 D103,D104,D105,D106
19.1 411020026020R DIO BAV99-LF 350mW 70V SOT-23ROHS (FEC) 4
19.2 411020026390R DIO BAV99,SOT-23(INFINEON)ROHS 4
FB101,FB102,FB104,FB105
FB106,FB107,FB108,FB109
FB110,FB111,FB112,FB113
20
432002360111R
BEAD CORE SMD(0805) 600Ω
2APBY201209T-601Y-N ROHS
13
FB114
21 410500045210R XSTR PMBT3904 NPN 200MA,40V SOT23(PHILIPS) 2
21.1 410500045140R
XSTR MMBT3904LT1G NPN 200MA40V
SOT23ROHS (ON) 2
21.2 410500045130R XSTR MMBT3904 NPN SOT-23(INFINEON) 2
22 410500068290R XSTR AP2305GN P-CH SOT23(APEC) 1 Q102
23 410500050210R XSTR 2N7002,N-CH FET SOT-23(PHILIPS) 1 Q104
23.4 410500050130R XSTR SN7002 N-C SOT-23(INFINEON) 1
24 410500046210R XSTR PMBT3906 PNP 200MA,40VSOT23(PHILIPS) 2 Q105,Q106
24.1 410500046180R XSTR MMBT3906LT1G PNP 200mA40V SOT23 (ON) 2
24.2 410500046130R XSTR MMBT3906 PNP SOT-23(INFINEON) 2
25 415754725080R RP(0612)4.7KΩx4 1/16W J 8P4R 4 RP101,RP102,RP103,RP104
8 RP105,RP106,RP107,RP108
26
415752205080R RP(0612)22Ωx4 1/16W J 8P4R
RP109,RP110,RP111,RP112
13 R101,R103,R104,R105,R119
R120,R130,R132,R133,R143
27
414916047250R
RES SMD (0603) 4.7KΩ J,RT
R145,R151,R152
28 414916010350R RES SMD (0603) 10KΩ J,RT ROHS 7
R102,R108,R125,R126,R147,
R148,R162
29 414916010450R RES SMD (0603) 100KΩ J,RT 1 R106
30 414916020350R RES SMD (0603) 20KΩ J,RT ROHS 1 R107
31 414916022050R RES SMD (0603) 22Ω J,RT ROHS 8
R170,R171,R172,R173,R174,
R175,R176,R177
32 414916750910R RES SMD (0603) 75Ω F,RT ROHS 3 R112,R113,R114
33 414916047050R RES SMD (0603) 47Ω J,RT ROHS 3 R115,R116,R117
R122,R123,R124,R127,R137
R140,R141,R149,R150,R153
34
414916010150R
RES SMD (0603) 100Ω J,RT ROHS
12
R154,R155
35 414916000050R RES SMD (0603) 0Ω J,RT ROHS 1 R128
36 414916022150R RES SMD (0603) 220Ω J,RT ROHS 2 R156,R157
37 414916390010R RES SMD (0603) 390Ω F,RT ROHS 1 R158
38 414916015250R RES SMD (0603) 1.5KΩ J,RT 2 R163,R164
39 414916100110R RES SMD (0603) 1KΩ F,RT ROHS 5 R167,R168,R178,R179,R134
40 414916015150R RES SMD (0603) 150Ω J,RT ROHS 1 R169
41 414916018150R RES SMD (0603) 180Ω J,RT ROHS 1 R161
42 414916010550R RES SMD (0603) 1MΩ J,RT ROHS 1 R131
43 414916082050R RES SMD (0603) 82Ω J,RT ROHS 3 R109,R110,R111
44 412000419700R IC AIC1084-18PM TO263(AIC)ROHS 1 U101
Q101,Q103
30
