- 46 -
Proprietary connecting of DVI box
The 44 pin of proprietary DVI box is defined as follows:
1 RX2- 23 SCART_FUNC
2 RX2+ 24 KEY3
3 RX1- 25 SCART
RGB_CON
4 RX1+ 26 SCL5V
5 RX0- 27 nYCOEN
6 RX0+ 28 SDA5V
7 RXC- 29 NVDSW_SEL
8 RXC+ 30 HSCL
9 GND 31 REST
10 GND 32 HSDA
11 Y0 33 DVI_ DETECT
12 Y1 34 CORD_ RESET
13 Y2 35 CORD_DETECT
14 Y3 36 ADO_L
15 Y4 37 DETECT
16 Y5 38 AGND
17 Y6 39 IR0
18 Y7 40 ADO_R
19 LLC VPC 41 V51R
20 KEY1 42 GND
21 GND 43 V12
22 KEY2 44 V12
