Chapter 1
Monitor Feature
Driving system TFT Color LCD
Size 22"
Pixel pitch 0.282(H) * 0.282 (V)mm
Viewable angle 160(H) x 170 (V) degree
Brightness panel: 300 cd/m2(typ)
Contrast Ratio 700:1 (typ)
LCD Panel
Response time 5ms (Tr+Tf)
Video R,G,B Analog, DVI box (optional)
Input Separate Sync H/V TTL
H-Frequency 31-81KHZ
V-Frequency 56-75HZ
Display Color 16.7 million Colors
Maximum Dot Clock ® 135MHz
Max Resolution 1440X900 @75HZ
Plug & Play VESA FPMPMI
ON Mode <50W
EPA ENERGY STAY OFF Mode <1W
Audio output Rated Power 2.0W rms(Per channel)
Input Connector D-Sub 15 pin, DVI connector (on DVI box)
Input Video Signal Analog : 0.7Vp-p,75OHM
Horizontal : 473.76mm
Screen Size (Active) Vertical : 296.1mm
Power Source 90~264 Vac, 47~63HZ
Environmental
Considerations
Operating Temp : 5 to 40 degree ;
Storage Temp : -20 to 60 degree ;
Operating Humidity : 10% to 85%
Weight (N.W.) 5.2kg
Dimension 513.8(W) x 417.7(H) x 203.8(D) mm
