Acer AL2671W - System Block Diagram

Chapter 1 3
System Block Diagram
System Block and Wiring Diagram
SCART RG
B
IO/B
connector 8pin
panel-20pin
connector 2pin
connector 10pin
connector 3pin
SPEAKER-L
PANEL
connector 62pin
INVERTER
Tuner
connector 12pin
POWER/B
SCART YU
V
KEY/B
MAIN/B
connector 12pin
A
UDIO/
B
SPEAKER-R
IR Receve
r
connector 4pin
connector 8pin
AV 3
connector 7pin
connector
4pin
connector 5pin
