70
Chapter 3
Removing the Volume Control Board
1.
See “Removing the Upper Cove
r” on page 59.
2.
Lift the V
olume Control Board FFC away from the Upper Cover to detach the adhesive.
3.
Remove the two screws securing the board to the Upper Cover
.
4.
Lift the board clear of the Upper Cover
.
Ste
p
Size
Quantity
Screw T
ype
V
olume Control
Board
M2.5*3
2
81
83
