50 Chapter 3
7. Remove the HDD2 cover as shown.
Removing the DIMM Modules
1. See “Removing the Battery Pack” on page 46.
2. Remove the Memory Module cover. See “Removing the Lower Covers” on page 49.
3. Push out the release latches on both sides of the DIMM socket to release the DIMM module.
4. Remove the DIMM module.
5. Repeat steps for the second DIMM module.
To Next Page
