43
Description Picture
TPV
Pa
rt No.
Acer Part No.
Bezel
A34T0517AGEBMM0500 60.MA60B.002
Panel
750TVG320EBC12N000 LK.32008.0
01
Rear Cover
A34T0518 GM IL0130
60.MA60B.001
Hinge Ass'y
Q37T007801
1AEP 42.M680B.001
Base
A34T0521AEP
1M0220
60.M680B.009
