Disassembly Procedures 1-17
6. Peel back the the touchpad tape (F) covering the touchpad module (Figure 1-19).
Figure 1-19. Touchpad Tape Location
7. Lift up the top edge of the touchpad module (G) to remove it from the top assembly
(Figure 1-20).
Figure 1-20. Touchpad Module Removal
F
G
WEEE Annex VII Component:
Touchpad module
