Acer ConceptD 500 - System Cover Replacement Procedures; Removing the Rear System Cover

UPGRADING YOUR COMPUTER -
3
System Upgrade
Removing the rear system cover
1. Before you proceed, make sure that you have turned
off your computer and all peripherals connected to it.
Read the Pre- installation instructions on page 2.
2. Release the Cable latch(1) and (2)
2
1
