23 Chapter 3
No Procedure Photo
1 Unscrew 6 screws in the
Bottom Cover, then, unplug 1
IR Receiver wire and 1 FPC
connector to remove Top
Cover Module.
2 Remove Keypad Board:
(1) Unscrew 4 screw and
unplug 1 FPC to remove the
Keypad Board.
(2) Separate all the keypad
components.
3 IR Receiver:
Tear off the mylar to remove
the IR Receiver directly.
2. Remove and disassemble Top Cover Module

Acer PD726 Specifications

General

Resolution	1024 x 768 (XGA)
Weight	3.5 kg
Display Type	DLP
Projection Technology	DLP
Projection Size	23 to 300 inches
Brightness	4000 lumens
Lamp Life	2000 hours (Standard), 3000 hours (Economy)
Inputs	VGA, S-Video, Composite Video, Component Video
