Chapter 3 24
No Procedure Photo
4 Remove Assy Manual Lens
Cap Module:
(1) Remove 4 screws to
remove the Lens Cap Module.
(2) Unscrew 2 screws in the
front & 2 screws in the back to
remove the Lens Cap.
(3) Unscrew 1 screw to
disassemble the Lens Cap;
then, loosen 6 tenons to
separate the Lens Cap
Module.
