Chapter 3 36
4. Assemble Air Duct / Light Cut / Thermal Switch
No Procedure Photo
1 Screw 1 screw to assemble
the Air Duct.
2 (1) Screw 5 screws to
assemble the Light Cut.
(1) Screw 1 screw to
assemble the Thermal Switch.
