Chapter 3
38
6.
Assemble Main Board &
Audio Board
No
Procedure
1
Screw 6 hex screws in the
Bottom Cover; then, plug in 10
connectors and 1 connector
in the Bottom and screw 5
screws to assemble the Main
Board &
Audio Board.
