EN-2
ATTACHING / REMOVING THE BASE
SCREEN POSITION ADJUSTMENT
In order to optimize the best viewing position, you can adjust the tilt of the
monitor by using both of your hands to hold the edges of the monitor as
shown in the figure below.
The monitor can be adjusted to 15 degrees up or 5 degrees down as indicated
by arrow below.
Note: Remove the monitor and monitor base from its packaging.
Carefully place the monitor face-down on a stable surface -- use a
cloth to avoid scratching the screen.
1.
Attach the monitor stand arm to the
base.
2.
Ensure that the base is locked onto the
monitor stand arm.
