SPECIFICATION
LCD Panel
Driving system TFT Color LCD
Size 23.8"W
(60cm)
Pixel pitch 0.275mm
250cd/m
2
(Typical)
Contrast 100,000,000:1Max. (ACM)
Viewable angle 178° (H) 178° (V) (CR
≥
10) (Typical)
Response time
Panel Type In-Plane Switching
Video
H-Frequency 30K-85KHz
V-Frequency 48-76Hz
Display Colors 16.7M Colors
Dot Clock 180MHz
Max. Resolution 1920x1080@75Hz
Plug & Play
Power consumption
@200cd/m
2
ON Mode 20W(typ.)
Standby mode 0.5W(typ.)
0.3W(typ.)
Input Connector
D-Sub
HDMI (Only HDMI Model)
Input Video Signal
Analog:0.7Vp-p(standard), 75 OHM, Positive
HDMI signal (Only HDMI-Input Model)
Speakers 2W x 2 (Only Audio-Input Model) (Typical)
Audio
Audio-Input (Only Audio-Input Model)
Audio-Output (Only Audio-Output Model)
Maximum Screen Size
Horizontal:527mm
Vertical:296mm
Power Source 100-240V~, 50/60Hz
Environmental
Considerations
Operating Temp: 0°C to 40°C
Storage Temp: -20°C to 60°C
Operating Humidity: 20% to 80%
Dimensions 540.2(W) x 394.2(H) x 211.8(D)mm
Weight (N. W.) 2.66kg Unit (net)
Mechanism spec
Tilt: -5° to + 15°
Swivel: No
Height adjustment: No
Pivot: No
Detachable foot stand: Yes
External
Controls:
Functions
Contrast
ACM
Super Sharpness
H. Position
V. Position
Focus
Clock
Gamma
Color Temp.
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Volume
Mute
Over Drive
AMD FreeSync
Refresh Rate Num
Language
OSD Timeout
Transparency
OSD Lock
Input
Auto Source
Wide Mode
Hot Key Assignment
DDC/CI
Quick Start Mode
Reset All Settings
