2-5 System Utilities
Main
The Main tab allows the user to set the system time and date, enable or disable boot option, and
enable or disable recovery.
Figure 2:2. BIOS Main
Parameter Description
System Time Sets the system time in 24-hour format.
System Date Sets the system date.
Total Memory Displays the total memory installed.
Video Memory Displays the video memory installed.
Quiet Boot
When enabled, displays the OEM (original equipment
manufacturer) screen during system boot instead of the traditional
POST screen.
Network Boot Enable or disable system boot from LAN (local area network).
F12 Boot Menu Enable or disable the use of boot menu during POST.
D2D Recovery
Enable or disable disc-to-disc recovery by pressing
Alt
+
F10
key
during POST.
Wake on LAN Enable or disable system to wake up from LAN.
SATA Mode Select the SATA controller mode: AHCI or IDE.
Wi-Fi Enable or disable the Wi-Fi.
Bluetooth Enable or disable the Bluetooth.
Card Reader Enable or disable the Card Reader.
F9 Setup Defaults
F10 Save and Exit
F1
Esc
Help
Exit
Select Item
Select Menu
Enter
F5/F6
Select Sub-Menu
Change Values
InsydeH20 Setup Utility Rev. 3.7
Main
System Time : [19:03:49]
System Date : [01/01/2012]
Total Memory: 2048 MB
Video Memory: 128MB
Quiet Boot [Enable]
Network Boot [Enable]
F12 Boot Menu [Disable]
D2D Recovery [Enable]
Wake on LAN [Disable]
SATA Mode [AHCI Mode]
Wi-Fi [Enable]
Bluetooth [Enable]
Card Reader [Enable]
USB ports [Enable]
Wired Lan [Enable]
Audio [Enable]
Camera [Enable]
Power-off USB Charge [Disable]
Battery Threshold [20%]
Information Security ExitBoot
This is the help of the
[Hour:Minute:Second] field. Hour valid
range is from 0 to 23, Minute is from 0
to 59, Second is from 0 to 59.
INCREASE/
REDUCE : F6/F5.
Item Specific Help
