Acer TravelMate B113-M User Manual

Jumper and Connector Locations 3-5
IO Board View
Figure 3:4. IO Board Jumper
Table 3:4. IO Board Jumper
Item Description
JMIC1 Internal MIC Connector
JUSB1 USB2.0 Connector
JUSB2 USB2.0 Connector
JCOM1 Combo Jack Connector
JIO1 IO/B FFC Hot-bar
JUSB1
JMIC1
JUSB2
JCOM1
JIO1
Top View Bottom View

Acer TravelMate B113-M Specifications

General

Resolution	1366 x 768
Operating System	Windows 8 Pro
Battery Life	Up to 5 hours
Graphics	Intel HD Graphics
Battery	4-cell Li-ion
Processor	Intel Celeron
Display	11.6 inches
RAM	DDR3
Storage	500 GB HDD
