5. Power Board
No power
Check to CN902 Pin10,11 =14V and Pin6,7 = 5 V
OK
Check Interface board
Check AC line volt 120V or 220V
Change F901, Check BD901, L901, IC901
Check the voltage of C905(+)
Check bridge retified circuit
Check start voltage for the Pin2 of IC901
Change IC901
OK
Check the auxiliary voltage is smaller than 20V
OK
NG
No power
NG
NG
OK
Check T901,D906, D907, Q903,ZD921,ZD922,IC904,IC903
Check IC901
NG
OK
NG

Acer V193W - bm - 19" LCD Monitor Specifications

General

Screen Size	19 inches
Resolution	1440 x 900
Aspect Ratio	16:10
Brightness	300 cd/m²
Contrast Ratio	2000:1 (dynamic)
Response Time	5 ms
Input Connectors	VGA
Viewing Angles	170° horizontal, 160° vertical
