9
LCD Monitor General Specification
Driving system TFT Color LCD
Active Display Area 408.24 (H) x 255.15 (V)
Pixel pitch 0.2835(H) x 0.2835(W)
Contrast Ratio 800 : 1
Response time 5ms
LCD Panel
Luminance of White 300(Typ.) cd/
Separate Sync. H/V TTL
H-Frequency 30kHz – 80kHz
Input
V-Frequency 55-75Hz
Viewing angle (H)160 (V) 160(Type)
Display Colors 16.7M
Display mode 1440 x 900 @75Hz
ON Mode < 37W
EPA ENERGY STAR®
OFF Mode < 1W
Contrast control
Set to The va
lue under user mode, which allows that the brightest two of 32 linear
distributed gray-scales (0 700mv) can be distinguished.
Power Source 90 V ~ 240 V50 ± 3Hz, 60 ± 3Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -30° to 65°C
Operating Humidity: 0% to 90%
Storage Humidity: 0% to 90%
Peak surge current < 55A peak at 240 VAC and cold starting
Power line surge
No advance effects (no loss of information or defect) with a maximum of 1 half-
