Acer V223HQ User Manual

English
User
Main
menu
icon
Sub
menu
icon
Sub menu item Description
Contrast Adjusts the contrast between the
foreground and background of the
screen image.
Brightness Adjusts the background brightness of the
screen image.
ACM ACM (Adaptive Contrast Management)
ACM On/Off switch, default Off.
Focus Adjusts picture focus (available in analog
mode only).
Clock Adjusts the picture clock (available in
analog mode only).
H. Position Adjusts the horizontal position (available
in analog mode only).
V. Position Adjusts the vertical position (available in
analog mode only).
N/A Warm Sets the color temperature to warm
white.
N/A Cool Sets the color temperature to cool white.
User/red Adjusts red intensity.
User/green Adjusts green intensity.
User/blue Adjusts blue intensity.

Acer V223HQ Specifications

General

Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	268 mm
Contrast ratio (typical)	-
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Power management	ENERGY STAR
Display viewable area (HxV)	476.6 x 268 mm
Mean time between failures (MTBF)	50000 h
Certification	TCO03
Product color	Black
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.67 W
Power consumption (standby)	0.79 W
Power consumption (typical)	30 W

Weight and Dimensions

Depth (without stand)	195 mm
Width (without stand)	371.52 mm
Height (without stand)	507.84 mm
Weight (without stand)	4500 g
