V70MA System Board 23
Figure 10 Installing an ISA Card
12 USB
USB (Universal Serial Bus) is a new serial bus design that is capable
of cascading low-/medium-speed peripherals (less than 12 Mbps)
such as a keyboard, mouse, joystick, scanner, printer and
modem/ISDN. With USB, complex cable connections at the back
panel of your PC can be eliminated.
The board comes with two USB ports (CN1). See Figure 1 or Figure 2
for the location of the ports.
