Acer Veriton M430 - Rear Panel

Chapter 1 7
Rear Panel
No. Component
1 Power connector
2 PS2 keyboard connector
3 DVI port
4COM port
5 USB 2.0 ports
6 Microphone jack
7 Speaker out jack
8 Expansion slot(graphics card ect.)
9 Lock Handle
10 line-in jack
11 RJ45 LAN port
12 VGA Port
13 System Fan
14 PS2 mouse connector
15 Fan aperture
4
7
1
11
12
3
15
13
5
10
8
6
9
2
14
