60 Chapter 5
No Label Description No Label Description
1 CPU Socket AM3 938 socket for
CPU
2 PRINTER Printer header
3 PWR2 CPU Power
connector
4 CPU_FAN CPU fan power
header
5 DIMM CONN,DIMM,DDRIII,
1.5V,Blu,1mm,G/
F,G,DIP-240
6 MB_ID1~2 GPIO connector
7 TPM Trusted platform
module interface
header
8 FLOPPY Floppy device
connector
?9 PWR1 M/B main power
connector
10 SATA1~6 SATA data transfe
connector
11 C_INTRUSIO
N
Chassis intrusion
alarm header
12 F_PANEL
13 OBR 14 F_USB4 Front panel USB
headers
15 F_USB1~3 Card reader USB
headers
16 SYS_FAN SYS fan header
17 CLR_CMOS Clear CMOS jumpers 18 SPI SPI header
19 HBIOS_WP 20 COM2
21 SPDIF_OUT SPDIF out header 22 INT_SPK Internal speaker
header
23 AUDIO Front panel audio
header
24 PCI1 PCI socket
25 PCIE_1X1 PCIE_1x1 socket 26 PCIE_1X PCIE_1x socket
27 PCI-E1_16X PCIE_x16socket
