- 24 -
17 Assemble bracket ,
Cover the cover board
at last.
Attention L or R.
18 Assemble with
shackles.
19 Lock 2 screws for
fasteness.
Screw-driver：
7.5+0.5Kg*cm
Hole size:
￠3.35±0.05
Screw head:
＃2
Length:60-80
20 Lock 4 screws to RC.
Screw-driver：
7.5+0.5Kg*cm
Hole size:
￠3.35±0.05
Screw head:
＃2
Length:60-80
21 Cover the CLM of L and
R
