Acer –LCD-X193HQ
10
[MENU]
A. When OSD isn’t shown on screen, press [MENU] to enter OSD interface. The
OSD interface uses “ACER e Color Management” and “User” to instead
“Contrast” and “Brightness” separately. When press “ACER e Color
Management” to show “e Color OSD”, and press “User” to show OSD interface
before. The translations of “ACER e Color Management” and “User” are always
English.
B. When OSD displays, press [MENU] to perform function of menu icon that is
highlight or enter next level menu
[►], [◄]
A. When “MENU OSD” displays, press these keys to change the contents of an
adjustment item, or change an adjustment value
B. When “MENU OSD” un-displays, if it is with audio, press [►] to show “Audio”
OSD and increase the volume, press [◄] to show “Audio” OSD and decrease
the volume; else it has no use to press these keys.
[e Color ]
A. When OSD un-displays, press [e Color] to show “e Color OSD”, and press again
the OSD can not disappear, but the time of “e Color OSD” disappearing is reset
10 second again.
B. When OSD disappear not including “e Color OSD”, press [e Color] to show “e
Color OSD” OSD, the OSD before disappears, but the parameters of it should be
saved
[POWER] Power on or power off the monitor
5.2.2
Hot Key Operation
HOT KEY OPERATION
FUNCTION
AUTO
e Color
◄ ►
MENU POWER
FACTORY MODE
● ●
ON
Press [e Color ] & [MENU] at the
same time, and then press [POWER]
for DC power on. OSD menu will be
shown with
“
F
”
on the left top.
Select
“
F
”
for entering factory
mode.
5.3 OSD Structure
The On-Screen Display (OSD) shall be an easy to use icon based menu through keypad OSD buttons or
remote control unit. The unit shall leave the factory with all OSD controls set to their default values.
First Second Third Control Range Default Value
ACER eColor
Management
e
mpowering
Technology
---
Standard mode
User mode
50
Text mode 50
Standard
mode
50
Graphics
mode
60
Brightness
User
Contrast
0 ~ 100
Movie mode 56

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
