Acer X25

44
For G-Sync FW upgrade：
1. Materials list and connection
nvcygwin FW
Conversion Board:PTPCPQC4 Conversion CABLE:395GH20026DM007000 ARM-USB-TINY-H
USB 2.0 cable: 389G017553500H
G-Sync FW Update connection mode, The red box is shown below.
Power cable Power cable
Usb cable
ISP JIG: ARM-USB-TINY-H
Debug Port
Conversion Board:PTPCPQC4
