ACHI IR6000 - Rework Temperature Curve to Set Examples

深圳利洋焊接设备 Shenzhen LiYang welding Equipment Co., Ltd
LY
WWW.LYBGA.COM
17
Rework temperature curve to set examples
1．Lead
Sn63Pb37
slope/S
numeric
al value
℃
temperature℃
numeric
al value
℃
Temperature
time S
numeric
al value
S
r1 0.45 L1 85 d1 85
r2 1 L2 150 d2 40
r3 1 L3 185 d3 40
2．Lead-free
Sn96.5Ag3Cu0.5
slope/S
numeric
al value
℃
temperature℃
numeric
al value
℃
Temperature
time S
numeric
al value
S
r1 0.45 L1 85 d1 92
r2 1 L2 150 d2 40
r3 1 L3 180 d3 40
r4 1 L4 220 d4 40
3. Lead
(Computer)
slope/S
numeric
al value
℃
temperature℃
numeric
al value
℃
Temperature
time S
numeric
al value
S
r1 0.5 L1 90 d1 90
r2 0.85 L2 135 d2 45
r3 0.8 L3 170 d3 40
r4 1 L4 185 d4 45
4. Lead-free
(Computer)
slope/S
numeric
al value
℃
temperature℃
numeric
al value
℃
Temperature
time S
numeric
al value
S
r1 0.45 L1 90 d1 90
r2 1 L2 145 d2 40
r3 1 L3 180 d3 50
r4 1 L4 220 d4 45
5．For XBOX
slope/S
numeric
al value
℃
temperature℃
numeric
al value
℃
Temperature
time S
numeric
al value
S
r1 0.40 L1 90 d1 90
r2 0.85 L2 135 d2 40
r3 1 L3 170 d3 60
r4 1 L4 220 d4 65
6．For PS3
slope/S
numeric
al value
℃
temperature℃
numeric
al value
℃
Temperature
time S
numeric
al value
S
r1 0.40 L1 90 d1 90
r2 0.85 L2 135 d2 45
r3 1 L3 180 d3 60
r4 1 L4 220 d4 65
