Overview
The FSC-1 is a digital EC motor control. The control has a simple buon interface with a four digit LED
display. All programmable parameters can be accessed through the user menu with the buon interface.
There are two ECM connectors with modulang outputs, one 0-10V output, and one 0-10V DC input. The FSC-
1 is compable with Telco Green, Genteq, Nidec, and U.S. Motors. User parameters are stored in non-le
memory, and are retained en during a power outage.
The FSC-1 is powered by 24V AC.
Normal Opera�on
Pulse Applica�on
ry ten seconds the FSC-1 display will toggle between the current percent of run speed and the current
RPMs. The percent of run speed can be changed by using the and keys followed by the key to
your changes. You also he the on of using the control locally or remotely through a potenometer,
2 Speed Switch, or a 0-10V reference where 0V is 0% and 10V is 100%, unless erridden by the low speed and
high speed limits. You can access programming mode by holding the enter key for three seconds.
0-10 Applica�on
In the 0-10V applica you are prded a programmable 0-10V reference. The
display shows the selected ltage. The ltage is easily changed using the and
keys followed by the key to e your changes.
Programming
Please refer to the “FSC-1 Menu Map” on page 9 for parameters within program mode. To enter
program mode hold the key for three seconds “APPS” is displayed. Use the and keys to
to the desired menu parameter shown in column 1 of the menu map on page 9. To edit a menu
parameter press the key once on the desired parameter. The curre
nt lue will be displayed in column 2
and keys to change ues within a parameter. The
of the menu map on page 9. Also use
parameter will blink the user presses
to the changes or the key to cancel without
If a
key
is not pressed for seconds, the control will return to normal mode.
parameters are as follows:
1. “APPS”: Prompts the user to select which applican to uize.
2. “SP1”: Sets the speed of the motor for Setpoint 1.
3. “SP2”: Sets the speed of the motor for Setpoint 2.
4. “LSPD”: Sets the lowest possible speed the motor will operate at. If the buon is pressed one
more passed
the “LSPD” limit, the control will turn
5. “hSPD”: Sets the highest possible speed the motor can operate at.
6. “tyP”: Sets the type of motor the control is for. The FSC-1 is with
Genteq, Nidec and US motors.
7. “re”: Allows the user to select local control or remote control type.
8. Allows the user to the current number.
FSC-1 DIGITAL CONTROL SETUP
Control is only used on ECM motors
