Button
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
Fuse
For over current protection.
Only for remote control
By connect to the 1/4’’ microphone jack to control the unit for Stand by, Function and Mode
function.
Mains input
Connect to supply mains power.
DMX input/output
For DMX512 link, use 3/5-pin XLR plug cable to link the unit together.
4.2 Main Function
To select any of the given functions, press the MENU button up to when the required one is
showing on the display. Select the function by ENTER button and the display will blink. Use
DOWN and UP button to change the mode. Once the required mode has been selected,
Press ENTER button to store. Back to the main functions without any change press the
MENU button or wait for 8 seconds.
Hold MENU button to quit menu mode, the unit will run the built-in program you selected.
The main functions are shown below:
5A
