ACME Super Dotline - DMX512 Configuration

- 42 -
6.3 DMX512 Configuration
Please control the fixture by referring to the configurations below.
17 Channels (Mode 1):
CHANNEL
VALUE
FUNCTION
1
000-255
TILT
0°202°
2
000-255
TILT FINE
3
000-255
ZOOM
WideNarrow
4
000-255
DIMMER
0%100%
5
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
MAIN STROBE
Close
Open
Strobe from Slow to Fast
Open
Slow Open Fast Close from Slow to Fast
Open
Fast Open Slow Close from Slow to Fast
Open
Random Strobe from Slow to Fast
Open
6
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
LINE_W STROBE
Close
Open
Strobe from Slow to Fast
Open
Slow Open Fast Close from Slow to Fast
Open
Fast Open Slow Close from Slow to Fast
Open
Random Strobe from Slow to Fast
Open
7
000-007
008-015
LINE_RGB STROBE
Close
Open
Attentions:
 The unit will maintain the last condition until reset if you cut-off the DMX signal.
 For the channel Function, keep the value for about 3 seconds, then the
corresponding function will take into effect.
