ACME TORNADO - DMX512 Configuration

- 33 -
6.3 DMX512 Configuration
Please control the fixture by referring to the configurations below.
41 Channels (Mode 1):
CHANNEL
VALUE
FUNCTION
1
000-255
PAN 1
0°62°
2
000-255
PAN 1 FINE
3
000-255
TILT 1
0°225°
4
000-255
TILT 1 FINE
5
000-255
ZOOM 1
WideNarrow
6
000-255
PAN 2
0°62°
7
000-255
PAN 2 FINE
8
000-255
TILT 2
0°225°
9
000-255
TILT 2 FINE
10
000-255
ZOOM 2
WideNarrow
11
000-255
PAN 3
0°62°
12
000-255
PAN 3 FINE
13
000-255
TILT 3
0°225°
14
000-255
TILT 3 FINE
15
000-255
ZOOM 3
WideNarrow
16
000-255
PAN 4
0°62°
17
000-255
PAN 4 FINE
Attentions:
 The unit will maintain the last condition until reset if you cut-off the DMX signal.
 For the channel Function, keep the value for about 3 seconds, then the
corresponding function will take into effect.
