ACME TORNADO - Page 47

- 46 -
Pan 1/2/3/4/5 Reset Error
Pan 1/2/3/4/5 Encode Error
Pan 1/2/3/4/5 Encode No Find
Pan 1/2/3/4/5 Encode Disable
Check whether the encoder on the pan is damaged.
Check whether the lead connecting the encoder on the pan and the
PCB board is in poor contact or disconnected.
Check whether the encoder on the pan is damaged.
Check whether the lead connecting the encoder on the pan and the
PCB board is in poor contact or disconnected.
Check whether the position of the pan where the magnet is installed
falls off or is damaged.
Check whether there are obstacles in the pan operating range.
Check whether the Hall element on the pan is damaged.
Check whether the lead connecting the Hall element on the pan and
the PCB board is in poor contact or disconnected.
Check whether the motor on the pan is damaged.
Check whether the related circuit of the motor drive board on the pan
is damage.
