Register list ”quick-guide”
In- and output.
Analog input
Signal type
UINT32
INT32
INT32
INT32
INT32
INT32
INT32
Status/Alarm Actual value
Max.
yesterday
High limit
High alarm
limit
Low limit
Low alarm
limit
AI 1 0/4-20mA
Høj grænse 8:0
Lav grænse 8:2
20 192 22 2011 24 2019
Digital input
Signal type
UINT32
UINT32
UINT32
UINT32
UINT32
UINT32
UINT32
Status/Alarm pulse total pulses today
pulses
yesterday
Operating time
total (secs.)
Operating
time today
(secs.)
Operating time
yesterday
(secs.)
DI 1
”low” < 5V.
”high” > 12V.
4:0 500 600 700 550 650 750
DI 2
”low” < 5V.
”high” > 12V.
4:1 502 602 702 552 652 752
Description
(Seconds)
(Seconds)
(Seconds)
Digital output
Signal type
UINT32
UINT32
UINT32
UINT32
UINT32
UINT32
UINT32
Status/Alarm pulse total pulses today
pulses
yesterday
Operating time
total (secs.)
Operating time
today (secs.)
Operating time
yesterday
(secs.)
DO 1
Relay max 2A
2:3 804 904 1004 854 954 1054
DO 2
Relay max 2A
2:4 806 906 1006 856 956 1056
Description
(Seconds)
(Seconds)
(Seconds)
Pump
Signal type
UINT32
UINT32
UINT32
UINT32
UINT32
UINT32
UINT32
Status/Command
Starts
total
Starts
today
Starts
yesterday
Operating time
total (secs.)
Operating time
today (secs.)
Operating time
yesterday (secs.)
Pump
Reley max 12A
(Pump)
70 100 128 156 108 136 164
Description
See section “pump
word list”
(Seconds)
(Seconds)
(Seconds)
Pump control.
Time and date
UINT32
System
information
UINT32
System
information
UINT16
System
information
STR20/32
Seconds 80 Id number 0 TCP-port 2566 Name 2844
Minuttes 82 GSM-signal 94 GPRS-timeout 2564 Municipal 2854
Hours 84 IP-Address 2564
Geographical
location
2870
Day 86 APN 2548
Month 88
Year 90
