Antenna Motor
Cam
Gear Assembly
Antenna
Rivet, Plastic
Radiant Heater
Multi-Wave Spring Washer
Flat Washer
Lock Nut
Note:
Requires 15/16” (26mm)
Deep Socket
See Detail Below
*Note:
Plastic Rivet
cannot be reused.
Cam
Antenna Motor
Rivet, *Plastic
Gear Assembly
Alignment Arrows
Antenna
21
